Blackhawk 2×2 MIMO XPOL Antenna 698-2700MHz 8/9dBi

Blackhawk M2M Low Profile Antenna – MIMO 3G/4G/WiFi + GPS

The Blackhawk low profile antenna for GSM/3G/LTE/WIFI/GPS is an omni-directional antenna designed for mission critical M2M and IoT applications.

SKU: D2113 Category: Tag:
Read More

Description

FEATURES

  • Provides a 3dBi gain across 700 to 2700Mhz
  • Supports MIMO cellular 698-2700 MHz, MIMO Wi-Fi 2.4/5GHz and GPS / GLONASS
  • IP67 rated
  • compact low profile design without compromising on performance
  • Stud Mount or optional bracket mount
  • Low Loss RG58 3m cable with SMA Male connector
  • Antenna has a diameter of 143.6mm with a height of 65mm

SPECIFICATIONS

Electrical

GPS part:

Operating Frequency                      1575.42MHz
Band width  ±5 MHz
Gain                                            28±2dB Typical
V.S.W.R＜2.0
Polarization                           RHCP
RadiationOmni
Maximum Input Power50W
Impedance50Ώ
Noise Figure1.5dB
DC Voltage2.2-5.0V
DC current5-15mA
Antenna Radome MaterialABS

LTE Part:

Frequency range698-960/1710-2700MHZ.
VSWR2.0:1
Gain3dBi*2
PolarizationLinear
Impedance50Ω

WIFI Part:

Frequency range2.4/5GHZ
V.S.W.R2.5
Gain3dBi*2
PolarizationLinear
Impendance50Ω

Mechanical

Mounting MethodScrew
HousingBlack
CableRG316/RG178/RG174
Length3M(can be customization)*5
ConnectorSMA Male(can be customization)
Operating Temperature-40°C~+85°C
Humidity55%-75%RH
WaterproofIP67
Humidity95%~100%RH
Antenna DimensionФ143.6×65 mm
Weight1.2KG

Additional information

Weight1.0 kg
Dimensions20 × 30 × 10 cm
