Blackhawk 4G-5G Indoor Wall Mount Panel Antenna, 698 to 4000 MHz, Low PIM
The Blackhawk Indoor Wall Mount Antenna is designed to provide mobile coverage inside a room when connected to a cellular repeater system.
- Description
- Additional information
- Where to buy
Description
Indoor panel antennas are a lightweight and highly cost-effective means of projecting mobile coverage in a forward direction. An example may be placing the panel antenna facing down a hallway or on the rear wall of a supermarket.
Indoor panel antennas are semi-directional. They provide a moderate gain of 5 to 7 dBi. This ensures coverage is transmitted in a wide arc, typically between 60 and 90 degrees, depending on the frequency band.
The antenna supports all major 4G and 5G mobile networks globally and has a low-PIM design to broadcast multiple carriers from the one antenna.
FEATURES
- Provides a 5 dBi gain for 698 to 960 MHz
- Provides a 7 dBi gain for 1710 to 4000 MHz
Electrical Specifications | ||||
| Frequency Range, MHz | 698-806 | 806-960 | 1690-2700 | 3300-4000 |
| Gain, dBi | 5.0 | 6.0 | 8.0 | 7.0 |
| VSWR | ≤2.0 | ≤2.0 | ≤1.7 | ≤1.7 |
| Polarization | Vertical | |||
| PIM, 3rd Order, 2x20W | ≤-150 dBc | |||
| Front to Back Ratio | ≥8 dB | ≥9 dB | ≥14 dB | ≥10 dB |
| Horizontal Beamwidth | 92° | 90° | 65° | 55° |
| Vertical Beamwidth | 73° | 68° | 60° | 35° |
| Input Impedance | 50 Ω | |||
| Max. Input Power | 50 W | |||
| Lightning Protection | DC Ground | |||
Mechanical Specifications | ||||
| Connector | N | 4.3-10 DIN Female | |||
| Dimensions | 180x158x60 mm | |||
| Weight | 0.4 kg | |||
| Reflector Material | Aluminum | |||
| Radome Material | ABS (UV Stabilized) | |||
| Operating Temperature | -40° C to+65 °C | |||
Additional information
| Weight | 0.4 kg |
|---|---|
| Dimensions | 21 × 18 × 7 cm |
