Blackhawk M2M Omni Antenna – 3G/4G, (BH-MM-102)
Buy Online Now at Powertec.com.au
The Blackhawk M2M omni antenna is a super compact antenna capable of operating on any network in Australia, making it suitable for M2M communications on Telstra, Optus, and Vodafone.
With a height of only 82 mm, the antenna is also a fantastic option for low clearance vehicles, buses, and caravans. With a simple stud mount the antenna can be a great internal antenna for the Cel-Fi repeater system, in fact in multistory buildings or multi-level car parks the antenna makes for an excellent external antenna where multiple antennas must be mounted on the building roof.
<strong>FEATURES:</strong>
<ul>
<li>4 dBi gain across lower bands 698-960 MHz</li>
<li>5 dBi gain across bands 1710-2170 MHz</li>
<li>4 dBi gain across upper bands 2500-2700 MHz</li>
<li>Black ABS construction</li>
<li>Bracket mount included</li>
<li>3 m cable with pre-terminated SMA male connector</li>
<li>Ideal for Telstra, Vodafone, and Optus M2M applications.</li>
</ul>
ELECTRICAL SPECIFICATIONS
Frequency Range | 698-960 / 1710-2170 / 2500-2700 MHz |
Peak Gain | 4 / 5.2 / 4 dBi |
VSWR | ≤2.0:1 |
Polarization | Vertical linear |
Maximum Input Power | 50 W |
Impedance | 50 Ώ |
MECHANICAL SPECIFICATIONS
Input Connector | SMA Male |
Cable | 3 m PT195 LSHF |
Lightning Protection | DC Ground |
Construction | ABS, black |
Mounting | Wall mounting bracket |
Dimensions | Φ48×82 mm |
Weight | 220 g |
Operating Temperature | -40 to +70°C |
