Blackhawk LPDA Antenna 698-4000MHz 12/14dBi

Availability: In Stock

Buy Online Now at Powertec.com.au

Now 5G ready!
Operating on all 3G, 4G and 5G frequencies in Australia, this high-grade antenna can be used in a range of residential, commercial, and industrial mobile broadband applications on any mobile network. This is the ideal external antenna for Cel-Fi repeater systems.

ELECTRICAL SPECIFICATION

Frequency Range (MHz)698-960 / 1710-2700/ 3300-4000
Input Impedance50 Ω
Peak Gain12 / 14 dBi
VSWR≤2.5:1 / ≤1.8:1
PolarisationVertical, linear
Horizontal Beam-width55 / 42°
Vertical Beam-width46 / 34°
Maximum Input Power50 W
Category:

The Blackhawk LPDA Antenna provides an ideal solution for 3G/ 4G voice and data applications. With the rollout of new 3G, 4G and even 5G frequencies, traditional Yagi antennas just haven’t been able to keep up. LPDA antennas allow a single antenna to cover all frequencies with the high gain of a Yagi antenna that rural and remote areas demand. This one antenna can be used on any mobile phone network in Australia, in any area without worrying about compatibility.

A Log Periodic Dipole Antenna, or LPDA for short, is a clever antenna design that provides exceptional wide-band performance by phasing a series of elements together, much like an ordinary Yagi but with each successive element of a smaller (or larger) length. The result of this clever engineering is an antenna that holds high gain, with good tuning, across the entire cellular frequency range.

FEATURES

  • 12 dBi gain across lower bands 698-960 MHz
  • 14 dBi gain across bands 1710-2700 MHz
  • 12 dBi gain across upper bands 3300-4000 MHz
  • Ruggedised construction for Australian conditions
  • Fully welded, powder coat aluminium design
  • Stainless steel mounting clamp included
  • 30 cm tail with pre-terminated N Female connector
  • Ideal for high-speed 3G and 4G LTE applications.
  • Ideal for Telstra Next-G and 4GX networks, Optus, and Vodafone 3G/4G & 5G
Input ConnectorN Female
Cable30 cm cable tail
Lightning ProtectionDC Ground
Radiator MaterialFully welded aluminium, black powder coat
MountingStainless Steel, pole mount Ø30-50 mm
Dimensions1240 x 200 x 60 mm
Packing Dimensions1290 x 210 x 90 mm
Weight2.2 kg
Rated Wind Velocity192 km/h
Operating Temperature-40 to +65°C
